| Width (B)
Circuit-breaker panel for 1250A for 2000A |
Width (B)
Circuit-breaker panel 800 mm 1000 mm |
| Height (H)
With standard low-voltage compartment and IAC 0.1s |
Height (H)
2250 mm |
| Depth (T)
Standard |
Depth (T)
1900 mm |
| Classification | IAC |
Accessibility
|
Type A Type A Type A
|
| Test current Arc duration |
25 (kA) 1 (s) |
| Partition class | PM (metallic partition) |
| Loss of service continuity category | LSC2B (metal-clad) |
Compartment accessibility (standard)
|
Compartment accessibility (standard)
Tool-based Interlock-controlled Tool-based Connection compartment Interlock-controlled and Tool-based Tool-based |
